The machine body is compact and lightweight, equipped with a lightweight crawler/tyre chassis, allowing it to flexibly navigate through narrow mountain roads and fields without the need for auxiliary transportation by large equipment. The equipment can quickly complete the drilling of small and medium-sized water wells.
Core feature: Small body with great capability
1. Functional integration: Lightweight without simplification, no need for external equipment
2. Practical performance: Adaptable to small and medium deep holes, capable of handling common strata
3. Safety Fundamentalization: No Lack of Key Protections
4. Environmental Adaptability: Coping with Basic Working Conditions in Mountainous Areas
Technical Parameter
| (t)The Weight | 2.7 |
| (mm)The Hole Diameter | 130-254 |
| (m)Drilling Depth | 180 |
| (m)One-time Advance Length | 2.4 |
| (km/h)Walking Speed | 2.5 |
| (Max.)Climbing Angles | 30 |
| (kW)Main Engine Power | 77.3玉柴Yuchai |
| (mpa)Working Air Pressure | 1.7-2.5 |
| (m³/min)Air Consumption | 17-31 |
| (mm)Drill Pipe Diameter | 76/89 |
| (m)Drill Pipe Length | 1.5/2.0 |
| (t)Rig Lifting Force | J5 |
| (rpm)Swing Speed | 45-65 |
| (N.m)Swing Torque | 4000-4600 |
| (mm)Dimension | 2300 ㄤ靜 1200 x 1900 |
